Specification
Name
Portable Ultra Low Temperature Freezer
Type
DM-8625
Storage Volume
25L
Electric Power
100V AC to 240V AC；50Hz,60Hz；12V DC to 24V DC
Maximum Power
100W (0.5A@220V,4.6A@24V)
Cooling Engine
Free-piston Stirling Engine
Refrigerant
Helium (He)
Heat Transport System
Gravity driven thermosiphon
Temperature Range
25℃ to Minus 86℃
Environmental Conditions
Non-corrosive, Non-flammable, Non-explosive, Altitude up to 2000m

Temperature 5℃ to 35℃,maximum relative humidity 80%
Performance Data
Ambient temperature is 25℃；Empty Cabinet

Take 3.5 hours from 25℃ to -80℃
Steady State Energy
Ambient temperature is 25℃

75W
Insulation
High performance vacuum insulated panels, polyurethane foam
Noise
＜55dB
Control Sensor
One RTD(PT100 Class B),precision±0.3
Security
Lockable lid
Warm and cold alarms
Setpoint ±10℃
Defrost Method
Manual
Certification
CE/EMC、CE/LVD、CQC
Interior(LxWxD)
300*250*300mm
Exterior(LxWxD)
616*392*455mm
Net Weight, Empty
17.5KG
Shipping(LxWxD)
969*472*522mm
Shipping Weight
20KG
