Specification
Brand

Engine
N20
Application
X1/X3/Z4
Part Type
Connecting Rods
Center to Center Length:
144.35mm
Big End Bore Diameter:
53.620mm
Big End Width:
20.88mm
Small End Bore Diameter:
22mm
Small End Width:
20.88mm
Beam Style:
H-beam
Connecting Rod Bolt
Sold it as separately
Approximate Connecting Rod Weight
/
Advertised Horsepower Rating
600hp
Quantity
Sold as 4 pieces /set
Material
Forged 4340 steel
Connecting Rod Finish
Shot-peened, Polished
Pin
Bronze wrist pin bushings
Wrist Pin Style
Floating
Cap Retention Style
Cap screw
Private Label
Yes ,available
Custom design
Yes, accept
Packing
neutral carton box
Applicable type
Why Choose Us
Company Profile


Customer Photos


FAQ
Q1: What's the material for forged piston ?
A1: matenal is 4032

Q2: Can you accept small quantity order ?
A2: Yes, If for standard model we can send it within 3 working days.

Q3: Can you custom piston if supply sample?
A3: Yes, we can customized as your requirement and your sample on drawing when you reach our MOQ.

Q4: Would you send the sample before place an order ?
A4: We can supply the sample for testing with sample fee and express cost.

Q5: Can laser my logo on the piston?
A5: Yes, we can do laser logo on piton top or sbove pin sest

Q6: Could you make coating in skirt ?
A6 Yes, but the prise wl be dfteret from without coating .

Q7: How about the delivery time ?
A7: About 15~25 working days for production, within 3 days for stock model.

Q8: How aboul the payment term ?
A8. By TIT By Wlestem Union, By Paypal, By cash

Q9: How about the Shipping Method?
A9: DHLUPS/TNT/Fedex and other alr shipments and sea shipments are all workable.
